Material list

Device	Reference
Bench power supply	RUZIZAO - 30V 5A DC
Portable Oscilloscope	Hantek - 6022BE - digital oscilloscope 2 channels 20 MHz
Desk Oscilloscope	Hantek - DSO4072C - digital oscilloscope 2 channels 70 MHz hacked to 200MHz
Wave-forme generator	Hantek - DSO4072C - Wave-forme generator 25MHz
Soldering microscope	Andonstar AD246S MUSTOOL 3.5X - 90X Double Boom Trinocular with 41MP camera
Soldering iron	TS 100 Soldering Tips : - TS-I - TS-BC3 - T12-B2 - TS-JL02 - T12-ILS - TS-KU
Hot air station	TOOLOUR 100-500°C
Multimeter	ANENG Q1
CH341A	TECNOIOT CH341A
Logic analyzer	DSLogic Plus 400MHz No name 24MHz - 8 channels
ISP programmer	ISP-MKII
USB > UART	FT232RL Silicon Lab - CP2104
USB capacity tester	Keweisi 3.5v-9v 0-3.3A
